Specifications Chart
20"
22"
24"
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XD86429050300 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 5X127 | 5.00 | 00mm | 71.50 | 37.60 lbs | 2500 | 2.01 | T167L1335S1-H34 | $390.00 |
| XD86429050318 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 5X127 | 5.71 | 18mm | 71.50 | 36.40 lbs | 2500 | 2.01 | T167L1335S1-H34 | $390.00 |
| XD86429085300 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 5X139.7 | 5.00 | 00mm | 78.10 | 37.60 lbs | 2500 | 2.01 | T167L1455S1-H42 | $390.00 |
| XD86429058318 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 5X150 | 5.71 | 18mm | 110.10 | 36.40 lbs | 2500 | 2.01 | T167L1455S1-H42 | $390.00 |
| XD86429063300 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 6X135 | 5.00 | 00mm | 87.10 | 37.60 lbs | 2500 | 2.01 | T167L1406S1-H34 | $390.00 |
| XD86429063318 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 6X135 | 5.71 | 18mm | 87.10 | 36.40 lbs | 2500 | 2.01 | T167L1406S1-H34 | $390.00 |
| XD86429068300 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 37.60 lbs | 2500 | 2.01 | T167L1456S1-H42 | $390.00 |
| XD86429068318 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 6X139.7 | 5.71 | 18mm | 106.10 | 36.40 lbs | 2500 | 2.01 | T167L1456S1-H42 | $390.00 |
| XD86429080318 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 8X165.1 | 5.71 | 18mm | 125.10 | 39.30 lbs | 3700 | 2.01 | T167L1708S1A-H50 | $390.00 |
| XD86429080300 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 8X165.1 | 5.00 | 00mm | 125.10 | 40.40 lbs | 3700 | 2.01 | T167L1708S1A-H50 | $390.00 |
| XD86429087300 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 8X170 | 5.00 | 00mm | 125.10 | 40.40 lbs | 3700 | 2.01 | T167L1708S1A-H63 | $390.00 |
| XD86429087318 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 8X170 | 5.71 | 18mm | 125.10 | 39.30 lbs | 3700 | 2.01 | T167L1708S1A-H63 | $390.00 |
| XD86429088318 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 8X180 | 5.71 | 18mm | 124.20 | 39.30 lbs | 3700 | 2.01 | T167L1708S1A-H50 | $390.00 |
| XD86429088300 | XD864 ROVER | GLOSS BLACK MILLED | 20X9 | 8X180 | 5.00 | 00mm | 124.20 | 40.40 lbs | 3700 | 2.01 | T167L1708S1A-H50 | $390.00 |
| XD86421050318N | XD864 ROVER | GLOSS BLACK MILLED | 20X10 | 5X127 | 4.79 | -18mm | 71.50 | 39.10 lbs | 2500 | 3.21 | T167L1335S1-H34 | $406.00 |
| XD86421085318N | XD864 ROVER | GLOSS BLACK MILLED | 20X10 | 5X139.7 | 4.79 | -18mm | 78.10 | 39.10 lbs | 2500 | 3.21 | T167L1455S1-H42 | $406.00 |
| XD86421063318N | XD864 ROVER | GLOSS BLACK MILLED | 20X10 | 6X135 | 4.79 | -18mm | 87.10 | 39.10 lbs | 2500 | 3.21 | T167L1406S1-H34 | $406.00 |
| XD86421068318N | XD864 ROVER | GLOSS BLACK MILLED | 20X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 39.10 lbs | 2500 | 3.21 | T167L1456S1-H42 | $406.00 |
| XD86421080318N | XD864 ROVER | GLOSS BLACK MILLED | 20X10 | 8X165.1 | 4.79 | -18mm | 125.10 | 41.30 lbs | 3700 | 3.21 | T167L1708S1A-H50 | $406.00 |
| XD86421087318N | XD864 ROVER | GLOSS BLACK MILLED | 20X10 | 8X170 | 4.79 | -18mm | 125.10 | 41.30 lbs | 3700 | 3.21 | T167L1708S1A-H63 | $406.00 |
| XD86421088318N | XD864 ROVER | GLOSS BLACK MILLED | 20X10 | 8X180 | 4.79 | -18mm | 124.20 | 41.30 lbs | 3700 | 3.21 | T167L1708S1A-H50 | $406.00 |
| XD86421063118N | XD864 ROVER | POLISHED | 20X10 | 6X135 | 4.79 | -18mm | 87.10 | 39.10 lbs | 2500 | 3.21 | T167L1406-H34 | $455.00 |
| XD86421068118N | XD864 ROVER | POLISHED | 20X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 39.20 lbs | 2500 | 3.21 | T167L1456-H42 | $455.00 |
| XD86421080118N | XD864 ROVER | POLISHED | 20X10 | 8X165.1 | 4.79 | -18mm | 125.10 | 41.30 lbs | 3700 | 3.21 | T167L1708A-H50 | $455.00 |
| XD86421087118N | XD864 ROVER | POLISHED | 20X10 | 8X170 | 4.79 | -18mm | 125.10 | 41.30 lbs | 3700 | 3.21 | T167L1708A-H63 | $455.00 |
| XD86421088118N | XD864 ROVER | POLISHED | 20X10 | 8X180 | 4.79 | -18mm | 124.20 | 41.30 lbs | 3700 | 3.21 | T167L1708A-H50 | $455.00 |
| XD86429050718 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 5X127 | 5.71 | 18mm | 71.50 | 36.40 lbs | 2500 | 2.01 | T167L1335S7-H34 | $366.00 |
| XD86429050700 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 5X127 | 5.00 | 00mm | 71.50 | 37.60 lbs | 2500 | 2.01 | T167L1335S7-H34 | $366.00 |
| XD86429085700 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 5X139.7 | 5.00 | 00mm | 78.10 | 37.60 lbs | 2500 | 2.01 | T167L1455S7-H42 | $366.00 |
| XD86429058718 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 5X150 | 5.71 | 18mm | 110.10 | 36.40 lbs | 2500 | 2.01 | T167L1455S7-H42 | $366.00 |
| XD86429063718 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 6X135 | 5.71 | 18mm | 87.10 | 36.40 lbs | 2500 | 2.01 | T167L1406S7-H34 | $366.00 |
| XD86429063700 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 6X135 | 5.00 | 00mm | 87.10 | 37.60 lbs | 2500 | 2.01 | T167L1406S7-H34 | $366.00 |
| XD86429068700 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 37.60 lbs | 2500 | 2.01 | T167L1456S7-H42 | $366.00 |
| XD86429068718 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 6X139.7 | 5.71 | 18mm | 106.10 | 36.40 lbs | 2500 | 2.01 | T167L1456S7-H42 | $366.00 |
| XD86429080700 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 8X165.1 | 5.00 | 00mm | 125.10 | 40.40 lbs | 3700 | 2.01 | T167L1708S7A-H50 | $366.00 |
| XD86429080718 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 8X165.1 | 5.71 | 18mm | 125.10 | 39.30 lbs | 3700 | 2.01 | T167L1708S7A-H50 | $366.00 |
| XD86429087700 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 8X170 | 5.00 | 00mm | 125.10 | 40.40 lbs | 3700 | 2.01 | T167L1708S7A-H63 | $366.00 |
| XD86429087718 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 8X170 | 5.71 | 18mm | 125.10 | 39.30 lbs | 3700 | 2.01 | T167L1708S7A-H63 | $366.00 |
| XD86429088718 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 8X180 | 5.71 | 18mm | 124.20 | 39.30 lbs | 3700 | 2.01 | T167L1708S7A-H50 | $366.00 |
| XD86429088700 | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X9 | 8X180 | 5.00 | 00mm | 124.20 | 40.40 lbs | 3700 | 2.01 | T167L1708S7A-H50 | $366.00 |
| XD86421050718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X10 | 5X127 | 4.79 | -18mm | 71.50 | 39.10 lbs | 2500 | 3.21 | T167L1335S7-H34 | $382.00 |
| XD86421085718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X10 | 5X139.7 | 4.79 | -18mm | 78.10 | 39.10 lbs | 2500 | 3.21 | T167L1455S7-H42 | $382.00 |
| XD86421063718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X10 | 6X135 | 4.79 | -18mm | 87.10 | 39.10 lbs | 2500 | 3.21 | T167L1406S7-H34 | $382.00 |
| XD86421068718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 39.10 lbs | 2500 | 3.21 | T167L1456S7-H42 | $382.00 |
| XD86421080718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X10 | 8X165.1 | 4.79 | -18mm | 125.10 | 41.30 lbs | 3700 | 3.21 | T167L1708S7A-H50 | $382.00 |
| XD86421087718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X10 | 8X170 | 4.79 | -18mm | 125.10 | 41.30 lbs | 3700 | 3.21 | T167L1708S7A-H63 | $382.00 |
| XD86421088718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 20X10 | 8X180 | 4.79 | -18mm | 124.20 | 41.30 lbs | 3700 | 3.21 | T167L1708S7A-H50 | $382.00 |
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XD86422050318N | XD864 ROVER | GLOSS BLACK MILLED | 22X10 | 5X127 | 4.79 | -18mm | 71.50 | 45.60 lbs | 2500 | 3.21 | T167L1335S1-H34 | $470.00 |
| XD86422063318N | XD864 ROVER | GLOSS BLACK MILLED | 22X10 | 6X135 | 4.79 | -18mm | 87.10 | 45.60 lbs | 2500 | 3.21 | T167L1406S1-H34 | $470.00 |
| XD86422068318N | XD864 ROVER | GLOSS BLACK MILLED | 22X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 45.60 lbs | 2500 | 3.21 | T167L1456S1-H42 | $470.00 |
| XD86422080318N | XD864 ROVER | GLOSS BLACK MILLED | 22X10 | 8X165.1 | 4.79 | -18mm | 125.10 | 46.70 lbs | 3700 | 3.21 | T167L1708S1A-H50 | $470.00 |
| XD86422087318N | XD864 ROVER | GLOSS BLACK MILLED | 22X10 | 8X170 | 4.79 | -18mm | 125.10 | 46.70 lbs | 3700 | 3.21 | T167L1708S1A-H63 | $470.00 |
| XD86422088318N | XD864 ROVER | GLOSS BLACK MILLED | 22X10 | 8X180 | 4.79 | -18mm | 124.20 | 46.70 lbs | 3700 | 3.21 | T167L1708S1A-H50 | $470.00 |
| XD86422263344N | XD864 ROVER | GLOSS BLACK MILLED | 22X12 | 6X135 | 4.77 | -44mm | 87.10 | 48.00 lbs | 2500 | 5.24 | T167L1406S1-H34 | $523.00 |
| XD86422268344N | XD864 ROVER | GLOSS BLACK MILLED | 22X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 48.00 lbs | 2500 | 5.24 | T167L1456S1-H42 | $523.00 |
| XD86422280344N | XD864 ROVER | GLOSS BLACK MILLED | 22X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 50.10 lbs | 3700 | 5.24 | T167L1708S1A-H50 | $523.00 |
| XD86422287344N | XD864 ROVER | GLOSS BLACK MILLED | 22X12 | 8X170 | 4.77 | -44mm | 125.10 | 50.10 lbs | 3700 | 5.24 | T167L1708S1A-H63 | $523.00 |
| XD86422288344N | XD864 ROVER | GLOSS BLACK MILLED | 22X12 | 8X180 | 4.77 | -44mm | 124.20 | 50.10 lbs | 3700 | 5.24 | T167L1708S1A-H50 | $523.00 |
| XD86422063118N | XD864 ROVER | POLISHED | 22X10 | 6X135 | 4.79 | -18mm | 87.10 | 45.60 lbs | 2500 | 3.21 | T167L1406-H34 | $515.00 |
| XD86422068118N | XD864 ROVER | POLISHED | 22X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 45.60 lbs | 2500 | 3.21 | T167L1456-H42 | $515.00 |
| XD86422080118N | XD864 ROVER | POLISHED | 22X10 | 8X165.1 | 4.79 | -18mm | 125.10 | 46.70 lbs | 3700 | 3.21 | T167L1708A-H50 | $515.00 |
| XD86422087118N | XD864 ROVER | POLISHED | 22X10 | 8X170 | 4.79 | -18mm | 125.10 | 46.70 lbs | 3700 | 3.21 | T167L1708A-H63 | $515.00 |
| XD86422088118N | XD864 ROVER | POLISHED | 22X10 | 8X180 | 4.79 | -18mm | 124.20 | 46.70 lbs | 3700 | 3.21 | T167L1708A-H50 | $515.00 |
| XD86422268144N | XD864 ROVER | POLISHED | 22X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 48.00 lbs | 2500 | 5.24 | T167L1456-H42 | $592.00 |
| XD86422280144N | XD864 ROVER | POLISHED | 22X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 50.10 lbs | 3700 | 5.24 | T167L1708A-H50 | $592.00 |
| XD86422287144N | XD864 ROVER | POLISHED | 22X12 | 8X170 | 4.77 | -44mm | 125.10 | 50.10 lbs | 3700 | 5.24 | T167L1708-H63 | $592.00 |
| XD86422288144N | XD864 ROVER | POLISHED | 22X12 | 8X180 | 4.77 | -44mm | 124.20 | 50.10 lbs | 3700 | 5.24 | T167L1708A-H50 | $592.00 |
| XD86422050718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X10 | 5X127 | 4.79 | -18mm | 71.50 | 45.60 lbs | 2500 | 3.21 | T167L1335S7-H34 | $428.00 |
| XD86422063718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X10 | 6X135 | 4.79 | -18mm | 87.10 | 45.60 lbs | 2500 | 3.21 | T167L1406S7-H34 | $428.00 |
| XD86422068718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 45.60 lbs | 2500 | 3.21 | T167L1456S7-H42 | $428.00 |
| XD86422080718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X10 | 8X165.1 | 4.79 | -18mm | 125.10 | 46.70 lbs | 3700 | 3.21 | T167L1708S7A-H50 | $428.00 |
| XD86422087718N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X10 | 8X170 | 4.79 | -18mm | 125.10 | 46.70 lbs | 3700 | 3.21 | T167L1708S7A-H63 | $428.00 |
| XD86422263744N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X12 | 6X135 | 4.77 | -44mm | 87.10 | 48.00 lbs | 2500 | 5.24 | T167L1406S7-H34 | $504.00 |
| XD86422268744N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 48.00 lbs | 2500 | 5.24 | T167L1456S7-H42 | $504.00 |
| XD86422280744N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 50.10 lbs | 3700 | 5.24 | T167L1708S7A-H50 | $504.00 |
| XD86422287744N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X12 | 8X170 | 4.77 | -44mm | 125.10 | 50.10 lbs | 3700 | 5.24 | T167L1708S7A-H63 | $504.00 |
| XD86422288744N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 22X12 | 8X180 | 4.77 | -44mm | 124.20 | 50.10 lbs | 3700 | 5.24 | T167L1708S7A-H50 | $504.00 |
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XD86424268344N | XD864 ROVER | GLOSS BLACK MILLED | 24X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 47.62 lbs | 2500 | 5.13 | T167L1456S1-H42 | $609.00 |
| XD86424280344N | XD864 ROVER | GLOSS BLACK MILLED | 24X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 50.04 lbs | 3700 | 5.13 | T167L1708S1A-H50 | $609.00 |
| XD86424287344N | XD864 ROVER | GLOSS BLACK MILLED | 24X12 | 8X170 | 4.77 | -44mm | 125.10 | 50.04 lbs | 3700 | 5.13 | T167L1708S1A-H63 | $609.00 |
| XD86424288344N | XD864 ROVER | GLOSS BLACK MILLED | 24X12 | 8X180 | 4.77 | -44mm | 124.20 | 50.60 lbs | 3700 | 5.13 | T167L1708S1A-H50 | $609.00 |
| XD86424268144N | XD864 ROVER | POLISHED | 24X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 47.62 lbs | 2500 | 5.13 | T167L1456-H42 | $697.00 |
| XD86424280144N | XD864 ROVER | POLISHED | 24X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 50.04 lbs | 3700 | 5.13 | T167L1708A-H50 | $697.00 |
| XD86424287144N | XD864 ROVER | POLISHED | 24X12 | 8X170 | 4.77 | -44mm | 125.10 | 50.04 lbs | 3700 | 5.13 | T167L1708-H63 | $697.00 |
| XD86424288144N | XD864 ROVER | POLISHED | 24X12 | 8X180 | 4.77 | -44mm | 124.20 | 50.60 lbs | 3700 | 5.13 | T167L1708A-H50 | $697.00 |
| XD86424268744N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 24X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 47.62 lbs | 2500 | 5.13 | T167L1456S7-H42 | $587.00 |
| XD86424280744N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 24X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 50.04 lbs | 3700 | 5.13 | T167L1708S7A-H50 | $587.00 |
| XD86424287744N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 24X12 | 8X170 | 4.77 | -44mm | 125.10 | 50.04 lbs | 3700 | 5.13 | T167L1708S7A-H63 | $587.00 |
| XD86424288744N | XD864 ROVER | SATIN BLACK W/ GLOSS BLACK LIP | 24X12 | 8X180 | 4.77 | -44mm | 124.20 | 50.60 lbs | 3700 | 5.13 | T167L1708S7A-H50 | $587.00 |
