Specifications Chart
17"
20"
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XD86179050900 | XD861 STORM | CANDY RED | 17X9 | 5X127 | 5.00 | 00mm | 71.50 | 34.17 lbs | 2500 | 1.47 | T167L1335S9-H34 | $346.00 |
| XD86179068912N | XD861 STORM | CANDY RED | 17X9 | 6X139.7 | 4.53 | -12mm | 106.10 | 34.83 lbs | 2500 | 1.47 | T167L1456S9-H42 | $346.00 |
| XD86179068900 | XD861 STORM | CANDY RED | 17X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 33.28 lbs | 2500 | 1.47 | T167L1456S9-H42 | $346.00 |
| XD86179050612N | XD861 STORM | SAND | 17X9 | 5X127 | 4.53 | -12mm | 71.50 | 35.27 lbs | 2500 | 1.47 | T167L1335S8-H34 | $346.00 |
| XD86179050600 | XD861 STORM | SAND | 17X9 | 5X127 | 5.00 | 00mm | 71.50 | 34.17 lbs | 2500 | 1.47 | T167L1335S8-H34 | $346.00 |
| XD86179068612N | XD861 STORM | SAND | 17X9 | 6X139.7 | 4.53 | -12mm | 106.10 | 34.83 lbs | 2500 | 1.47 | T167L1456S8-H42 | $346.00 |
| XD86179068600 | XD861 STORM | SAND | 17X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 33.28 lbs | 2500 | 1.47 | T167L1456S8-H42 | $346.00 |
| XD86179050700 | XD861 STORM | SATIN BLACK | 17X9 | 5X127 | 5.00 | 00mm | 71.50 | 34.17 lbs | 2500 | 1.47 | T167L1335S7-H34 | $346.00 |
| XD86179050712N | XD861 STORM | SATIN BLACK | 17X9 | 5X127 | 4.53 | -12mm | 71.50 | 35.27 lbs | 2500 | 1.47 | T167L1335S7-H34 | $346.00 |
| XD86179068712N | XD861 STORM | SATIN BLACK | 17X9 | 6X139.7 | 4.53 | -12mm | 106.10 | 34.83 lbs | 2500 | 1.47 | T167L1456S7-H42 | $346.00 |
| XD86179068700 | XD861 STORM | SATIN BLACK | 17X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 33.28 lbs | 2500 | 1.47 | T167L1456S7-H42 | $346.00 |
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XD86129063900 | XD861 STORM | CANDY RED | 20X9 | 6X135 | 5.00 | 00mm | 87.10 | 44.31 lbs | 2500 | 1.47 | T167L1406S9-H34 | $411.00 |
| XD86129063918 | XD861 STORM | CANDY RED | 20X9 | 6X135 | 5.71 | 18mm | 87.10 | 44.31 lbs | 2500 | 1.47 | T167L1406S9-H34 | $411.00 |
| XD86129068900 | XD861 STORM | CANDY RED | 20X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 42.55 lbs | 2500 | 1.47 | T167L1456S9-H42 | $411.00 |
| XD86129068918 | XD861 STORM | CANDY RED | 20X9 | 6X139.7 | 5.71 | 18mm | 106.10 | 43.65 lbs | 2500 | 1.47 | T167L1456S9-H42 | $411.00 |
| XD86121050918N | XD861 STORM | CANDY RED | 20X10 | 5X127 | 4.79 | -18mm | 71.50 | 46.08 lbs | 2500 | 1.47 | T167L1335S9-H34 | $446.00 |
| XD86121063918N | XD861 STORM | CANDY RED | 20X10 | 6X135 | 4.79 | -18mm | 87.10 | 44.75 lbs | 2500 | 1.47 | T167L1406S9-H34 | $446.00 |
| XD86121068918N | XD861 STORM | CANDY RED | 20X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 44.31 lbs | 2500 | 1.47 | T167L1456S9-H42 | $446.00 |
| XD86129050600 | XD861 STORM | SAND | 20X9 | 5X127 | 5.00 | 00mm | 71.50 | 43.65 lbs | 2500 | 1.47 | T167L1335S8-H34 | $411.00 |
| XD86129063600 | XD861 STORM | SAND | 20X9 | 6X135 | 5.00 | 00mm | 87.10 | 44.31 lbs | 2500 | 1.47 | T167L1406S8-H34 | $411.00 |
| XD86129063618 | XD861 STORM | SAND | 20X9 | 6X135 | 5.71 | 18mm | 87.10 | 44.31 lbs | 2500 | 1.47 | T167L1406S8-H34 | $411.00 |
| XD86129068600 | XD861 STORM | SAND | 20X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 42.54 lbs | 2500 | 1.47 | T167L1456S8-H42 | $411.00 |
| XD86129068618 | XD861 STORM | SAND | 20X9 | 6X139.7 | 5.71 | 18mm | 106.10 | 43.65 lbs | 2500 | 1.47 | T167L1456S8-H42 | $411.00 |
| XD86121050618N | XD861 STORM | SAND | 20X10 | 5X127 | 4.79 | -18mm | 71.50 | 46.08 lbs | 2500 | 1.47 | T167L1335S8-H34 | $446.00 |
| XD86121063618N | XD861 STORM | SAND | 20X10 | 6X135 | 4.79 | -18mm | 87.10 | 44.75 lbs | 2500 | 1.47 | T167L1406S8-H34 | $446.00 |
| XD86121068618N | XD861 STORM | SAND | 20X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 44.31 lbs | 2500 | 1.47 | T167L1456S8-H42 | $446.00 |
| XD86129050700 | XD861 STORM | SATIN BLACK | 20X9 | 5X127 | 5.00 | 00mm | 71.50 | 43.65 lbs | 2500 | 1.47 | T167L1335S7-H34 | $411.00 |
| XD86129058718 | XD861 STORM | SATIN BLACK | 20X9 | 5X150 | 5.71 | 18mm | 110.10 | 44.31 lbs | 2500 | 1.47 | T167L1455S7-H42 | $411.00 |
| XD86129063700 | XD861 STORM | SATIN BLACK | 20X9 | 6X135 | 5.00 | 00mm | 87.10 | 44.31 lbs | 2500 | 1.47 | T167L1406S7-H34 | $411.00 |
| XD86129068718 | XD861 STORM | SATIN BLACK | 20X9 | 6X139.7 | 5.71 | 18mm | 106.10 | 43.65 lbs | 2500 | 1.47 | T167L1456S7-H42 | $411.00 |
| XD86129068700 | XD861 STORM | SATIN BLACK | 20X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 42.54 lbs | 2500 | 1.47 | T167L1456S7-H42 | $411.00 |
| XD86129080700 | XD861 STORM | SATIN BLACK | 20X9 | 8X165.1 | 5.00 | 00mm | 125.10 | 44.31 lbs | 3700 | 1.47 | T167L1708S7-H50 | $411.00 |
| XD86129088718 | XD861 STORM | SATIN BLACK | 20X9 | 8X180 | 5.71 | 18mm | 124.20 | 44.97 lbs | 3700 | 1.47 | T167L1708S7-H50 | $411.00 |
| XD86121050718N | XD861 STORM | SATIN BLACK | 20X10 | 5X127 | 4.79 | -18mm | 71.50 | 46.08 lbs | 2500 | 1.47 | T167L1335S7-H34 | $446.00 |
| XD86121063718N | XD861 STORM | SATIN BLACK | 20X10 | 6X135 | 4.79 | -18mm | 87.10 | 44.75 lbs | 2500 | 1.47 | T167L1406S7-H34 | $446.00 |
| XD86121068718N | XD861 STORM | SATIN BLACK | 20X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 44.31 lbs | 2500 | 1.47 | T167L1456S7-H42 | $446.00 |
| XD86121080718N | XD861 STORM | SATIN BLACK | 20X10 | 8X165.1 | 4.79 | -18mm | 125.10 | 45.41 lbs | 3700 | 1.47 | T167L1708S7-H50 | $446.00 |
| XD86121087718N | XD861 STORM | SATIN BLACK | 20X10 | 8X170 | 4.79 | -18mm | 125.10 | 45.41 lbs | 3700 | 1.47 | T167L1708S7-H63 | $446.00 |
