Specifications Chart
17"
20"
22"
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XD86079050900 | XD860 ONSLAUGHT | CANDY RED | 17X9 | 5X127 | 5.00 | 00mm | 71.50 | 34.60 lbs | 2500 | 0.00 | T167L1335S9-H34 | $317.00 |
| XD86079068912N | XD860 ONSLAUGHT | CANDY RED | 17X9 | 6X139.7 | 4.53 | -12mm | 106.10 | 35.20 lbs | 2500 | 0.00 | T167L1456S9-H42 | $317.00 |
| XD86079068900 | XD860 ONSLAUGHT | CANDY RED | 17X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 33.70 lbs | 2500 | 0.00 | T167L1456S9-H42 | $317.00 |
| XD86079050312N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 17X9 | 5X127 | 4.53 | -12mm | 71.50 | 35.70 lbs | 2500 | 0.00 | T167L1335S1-H34 | $327.00 |
| XD86079068300 | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 17X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 33.70 lbs | 2500 | 0.00 | T167L1456S1-H42 | $327.00 |
| XD86079068312N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 17X9 | 6X139.7 | 4.53 | -12mm | 106.10 | 35.20 lbs | 2500 | 0.00 | T167L1456S1-H42 | $327.00 |
| XD86079077600 | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 17X9 | 6X120 | 5.00 | 00mm | 66.90 | 34.60 lbs | 2500 | 0.00 | T167L1206S6-H34 | $295.00 |
| XD86079068612N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 17X9 | 6X139.7 | 4.53 | -12mm | 106.10 | 35.20 lbs | 2500 | 0.00 | T167L1456S6-H42 | $295.00 |
| XD86079068600 | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 17X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 33.70 lbs | 2500 | 0.00 | T167L1456S6-H42 | $295.00 |
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XD86029050900 | XD860 ONSLAUGHT | CANDY RED | 20X9 | 5X127 | 5.00 | 00mm | 71.50 | 37.50 lbs | 2500 | 0.00 | T167L1335S9-H34 | $396.00 |
| XD86029063900 | XD860 ONSLAUGHT | CANDY RED | 20X9 | 6X135 | 5.00 | 00mm | 87.10 | 37.50 lbs | 2500 | 0.00 | T167L1406S9-H34 | $396.00 |
| XD86029068900 | XD860 ONSLAUGHT | CANDY RED | 20X9 | 6X139.7 | 5.00 | 00mm | 106.10 | 37.50 lbs | 2500 | 0.00 | T167L1456S9-H42 | $396.00 |
| XD86029080900 | XD860 ONSLAUGHT | CANDY RED | 20X9 | 8X165.1 | 5.00 | 00mm | 125.10 | 38.50 lbs | 3700 | 0.00 | T167L1708S9-H50 | $396.00 |
| XD86029087900 | XD860 ONSLAUGHT | CANDY RED | 20X9 | 8X170 | 5.00 | 00mm | 125.10 | 38.50 lbs | 3700 | 0.00 | T167L1708S9-H63 | $396.00 |
| XD86029088900 | XD860 ONSLAUGHT | CANDY RED | 20X9 | 8X180 | 5.00 | 00mm | 124.20 | 38.50 lbs | 3700 | 0.00 | T167L1708S9-H50 | $396.00 |
| XD86021050918N | XD860 ONSLAUGHT | CANDY RED | 20X10 | 5X127 | 4.79 | -18mm | 71.50 | 40.30 lbs | 2500 | 0.00 | T167L1335S9-H34 | $469.00 |
| XD86021063918N | XD860 ONSLAUGHT | CANDY RED | 20X10 | 6X135 | 4.79 | -18mm | 87.10 | 40.30 lbs | 2500 | 0.00 | T167L1406S9-H34 | $469.00 |
| XD86021068918N | XD860 ONSLAUGHT | CANDY RED | 20X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 39.40 lbs | 2500 | 0.00 | T167L1456S9-H42 | $469.00 |
| XD86021087918N | XD860 ONSLAUGHT | CANDY RED | 20X10 | 8X170 | 4.79 | -18mm | 125.10 | 41.00 lbs | 3700 | 0.00 | T167L1708S9-H63 | $469.00 |
| XD86021250944N | XD860 ONSLAUGHT | CANDY RED | 20X12 | 5X127 | 4.77 | -44mm | 71.50 | 50.60 lbs | 2500 | 0.00 | T167L1335S9-H34 | $436.00 |
| XD86021268944N | XD860 ONSLAUGHT | CANDY RED | 20X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 49.70 lbs | 2500 | 0.00 | T167L1456S9-H42 | $436.00 |
| XD86021280944N | XD860 ONSLAUGHT | CANDY RED | 20X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 51.50 lbs | 3700 | 0.00 | T167L1708S9-H50 | $436.00 |
| XD86021287944N | XD860 ONSLAUGHT | CANDY RED | 20X12 | 8X170 | 4.77 | -44mm | 125.10 | 51.50 lbs | 3700 | 0.00 | T167L1708S9-H63 | $436.00 |
| XD86029050300 | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X9 | 5X127 | 5.00 | 00mm | 71.50 | 37.50 lbs | 2500 | 0.00 | T167L1335S1-H34 | $413.00 |
| XD86029063300 | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X9 | 6X135 | 5.00 | 00mm | 87.10 | 37.50 lbs | 2500 | 0.00 | T167L1406S1-H34 | $413.00 |
| XD86029080300 | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X9 | 8X165.1 | 5.00 | 00mm | 125.10 | 38.50 lbs | 3700 | 0.00 | T167L1708S1-H50 | $413.00 |
| XD86029087300 | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X9 | 8X170 | 5.00 | 00mm | 125.10 | 38.50 lbs | 3700 | 0.00 | T167L1708S1-H63 | $413.00 |
| XD86021050318N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X10 | 5X127 | 4.79 | -18mm | 71.50 | 40.30 lbs | 2500 | 0.00 | T167L1335S1-H34 | $477.00 |
| XD86021063318N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X10 | 6X135 | 4.79 | -18mm | 87.10 | 40.30 lbs | 2500 | 0.00 | T167L1406S1-H34 | $477.00 |
| XD86021068318N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 39.40 lbs | 2500 | 0.00 | T167L1456S1-H42 | $477.00 |
| XD86021080318N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X10 | 8X165.1 | 4.79 | -18mm | 125.10 | 41.00 lbs | 3700 | 0.00 | T167L1708S1-H50 | $477.00 |
| XD86021087318N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X10 | 8X170 | 4.79 | -18mm | 125.10 | 41.00 lbs | 3700 | 0.00 | T167L1708S1-H63 | $477.00 |
| XD86021263344N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X12 | 6X135 | 4.77 | -44mm | 87.10 | 50.60 lbs | 2500 | 0.00 | T167L1406S1-H34 | $445.00 |
| XD86021268344N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 49.70 lbs | 2500 | 0.00 | T167L1456S1-H42 | $445.00 |
| XD86021280344N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 51.50 lbs | 3700 | 0.00 | T167L1708S1-H50 | $445.00 |
| XD86021287344N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 20X12 | 8X170 | 4.77 | -44mm | 125.10 | 51.50 lbs | 3700 | 0.00 | T167L1708S1-H63 | $445.00 |
| XD86029063600 | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 20X9 | 6X135 | 5.00 | 00mm | 87.10 | 37.50 lbs | 2500 | 0.00 | T167L1406S6-H34 | $402.00 |
| XD86029080600 | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 20X9 | 8X165.1 | 5.00 | 00mm | 125.10 | 38.50 lbs | 3700 | 0.00 | T167L1708S6-H50 | $402.00 |
| XD86029087600 | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 20X9 | 8X170 | 5.00 | 00mm | 125.10 | 38.50 lbs | 3700 | 0.00 | T167L1708S6-H63 | $402.00 |
| XD86021063618N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 20X10 | 6X135 | 4.79 | -18mm | 87.10 | 40.30 lbs | 2500 | 0.00 | T167L1406S6-H34 | $462.00 |
| XD86021068618N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 20X10 | 6X139.7 | 4.79 | -18mm | 106.10 | 39.40 lbs | 2500 | 0.00 | T167L1456S6-H42 | $462.00 |
| XD86021080618N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 20X10 | 8X165.1 | 4.79 | -18mm | 125.10 | 41.00 lbs | 3700 | 0.00 | T167L1708S6-H50 | $462.00 |
| XD86021087618N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 20X10 | 8X170 | 4.79 | -18mm | 125.10 | 41.00 lbs | 3700 | 0.00 | T167L1708S6-H63 | $462.00 |
| XD86021263644N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 20X12 | 6X135 | 4.77 | -44mm | 87.10 | 50.60 lbs | 2500 | 0.00 | T167L1406S6-H34 | $419.00 |
| XD86021268644N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 20X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 49.70 lbs | 2500 | 0.00 | T167L1456S6-H42 | $419.00 |
| Part# | Model | Finish | Size | Bolt Pattern | Backspace | Offset | Bore | Weight | Load | Lip Size | Cap | MSRP USD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| XD86022250944N | XD860 ONSLAUGHT | CANDY RED | 22X12 | 5X127 | 4.77 | -44mm | 71.50 | 53.90 lbs | 2500 | 0.00 | T167L1335S9-H34 | $473.00 |
| XD86022268944N | XD860 ONSLAUGHT | CANDY RED | 22X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 53.90 lbs | 2500 | 0.00 | T167L1456S9-H42 | $473.00 |
| XD86022280944N | XD860 ONSLAUGHT | CANDY RED | 22X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 55.00 lbs | 3700 | 0.00 | T167L1708S9-H50 | $473.00 |
| XD86022287944N | XD860 ONSLAUGHT | CANDY RED | 22X12 | 8X170 | 4.77 | -44mm | 125.10 | 55.00 lbs | 3700 | 0.00 | T167L1708S9-H63 | $473.00 |
| XD86022250344N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 22X12 | 5X127 | 4.77 | -44mm | 71.50 | 53.90 lbs | 2500 | 0.00 | T167L1335S1-H34 | $482.00 |
| XD86022268344N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 22X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 53.90 lbs | 2500 | 0.00 | T167L1456S1-H42 | $482.00 |
| XD86022280344N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 22X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 55.00 lbs | 3700 | 0.00 | T167L1708S1-H50 | $482.00 |
| XD86022287344N | XD860 ONSLAUGHT | GLOSS BLACK MILLED | 22X12 | 8X170 | 4.77 | -44mm | 125.10 | 55.00 lbs | 3700 | 0.00 | T167L1708S1-H63 | $482.00 |
| XD86022268644N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 22X12 | 6X139.7 | 4.77 | -44mm | 106.10 | 53.90 lbs | 2500 | 0.00 | T167L1456S6-H42 | $456.00 |
| XD86022280644N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 22X12 | 8X165.1 | 4.77 | -44mm | 125.10 | 55.00 lbs | 3700 | 0.00 | T167L1708S6-H50 | $456.00 |
| XD86022287644N | XD860 ONSLAUGHT | SATIN BLACK W/ BRONZE TINT | 22X12 | 8X170 | 4.77 | -44mm | 125.10 | 55.00 lbs | 3700 | 0.00 | T167L1708S6-H63 | $456.00 |
